Description of the device
4.2 Product groups
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
57
4.2.1.9
SCALANCE X310 product characteristics
Possible attachments
The SCALANCE X310 provides the following options for the connection of end devices or
other network segments:
● 10 RJ-45 jacks
Image 4-9 SCALANCE X310
Column
1
2
3
4
Port number
P1
P5
P8
P9
P2
P6
-
P10
P3
P7
-
-
P4
-
-
-
Connection
type
Electrical: Fast Ethernet Electrical: Gigabit Ethernet
