8.6 XR-300M EEC technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
183
Table 8- 66 Full wire speed switching
Number of frames per second
45290 452899 256 bytes
Note
The following applies to IE
Switches X-300:
number of IE Switches X-300 connected in a line influences the frame delay time. When
a frame passes through the switch, this is delayed by the Store&Forward function of the
IE
Switch X-300 by the following values:
at 64 bytes frame length: Delay of approx. 10 microseconds (at 100 Mbps)
at 1500 bytes frame length: Delay of approx. 130 microseconds
(at 100 Mbps)
This means, the more IE Switches X
-300 a frame runs through, the higher the frame delay.
XR-300M EEC technical specifications
Note
Validity of the technical specifications
All the technical specifications described in this section that is not assigned to a specific
device variant, version or a media module, apply to all device variants/versions of the
product group.
