Description of the device
4.2 Product groups
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
75
MM992-2CU product characteristics
Possible attachments
The MM992-2CU media module has the following:
● 2 x 10/100/1000 Mbps, RJ-45 port electrical without securing collar
Image 4-26 MM992-2CU [9922SA]
[Device labeling in square brackets]
Note
For connection to electrical networks note the information in Appendix A.1 and A.2.
MM992-2VD product characteristics
Possible attachments
The MM992-2VD media module has the following:
● 2 x 10/100/1000 Mbps, RJ-45 ports electrical with securing collar
● Additional two-wire transfer function (variable distance) for establishing Ethernet
connections even using cables that do not conform to Ethernet. Possible distance
covered depends on the cable quality.
Image 4-27 MM992-2VD [9922VA]
[Device labeling in square brackets]
Note
For connection to electrical networks note the information in Appendix A.1 and A.2.
