Siemens SCALANCE X308-2 User Manual

Technical specifications
8.2 X-300 technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
161
Note
2 optical interface transceivers possible (X320-3LD FE)
The device is also equipped with 2 optical interface transceivers.
•
1)
Fast Ethernet, long distance interface
•
2)
Fast Ethernet, multimode interface
As a result, the
electrical data in the technical specifications is divided into two parts:
transmitter output optical and receiver input.
8.2.3
Cable lengths
Table 8- 10 Permitted cable lengths (copper cable - Fast Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE TP torsion cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 45 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 55 m
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 75 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 85 m
IE FC TP standard cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 100 m
Table 8- 11 Permitted cable lengths (copper cable - gigabit Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE FC standard cable, 4×2, 24
AWG
IE FC flexible cable, 4×2, 24
AWG
with IE FC RJ-45 Plug 180,
4x2
0 to 90 m
IE FC standard cable, 4×2, 22
AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 60 m
+ 10 m TP cord
IE FC flexible cable, 4×2, 22
AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
