Description of the device
4.2 Product groups
SCALANCE X-300
88 Operating Instructions, 05/2016, A5E01113043-20
Note
Only the media module MM992
-2SFP may be fitted with approved SFP transceivers. The
SFP media module can be fitted with up to two SFPs.
[Order number]
Labeling on the device
MM992-2SFP (2 x 100/1000 Mbps,
SFP media module)
[6GK5 992-2AS00-8AA0]
9922AS
multimode has a black clip and an SFP with single mode has a blue clip. To
protect the pins, these are fitted with a dummy plug.
Supported wavelengths of the SFPs
1310 nm
SFP991-1LH+ 1550 nm
SFP992-1 850 nm
1310 nm
1550 nm
