Description of the device
4.2 Product groups
SCALANCE X-300
56 Operating Instructions, 05/2016, A5E01113043-20
SCALANCE X308-2LD product characteristics
Possible attachments
The SCALANCE X308-2LD provides the following options for the connection of end devices
or other network segments:
● 8 RJ-45 jacks
● 2 FO ports (for single mode fiber)
Image 4-8 SCALANCE X308-2LD
P9
P3 P7 - P10
Electrical: Fast Ethernet
Electrical:
Optical:
