Technical specifications
8.3 X-300M technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
167
Table 8- 24 Electrical data: Current consumption and power loss
Device version
(power supply)
Current consumption
Effective power loss
12 VDC
1.4 A
16.6 W
24 VDC 0.7 A 16.6 W
Table 8- 25 Electrical data: Overcurrent protection
Device version
(power supply)
Overcurrent protection of the power supply
Non-replaceable fuse
12 VDC
3 A / 32 V
24 VDC 3 A / 32 V
Table 8- 26 Electrical data: Signaling contact
Device version
(power supply)
Voltage via signaling contact
Switching capacity (resistive
load)
12 VDC
12 VDC / 24 VDC
Max. 100 mA
24 VDC
24 VDC
Max. 100 mA
Table 8- 27 Plug-in terminal block for connectors of the power supply and signaling contact
Device version
(power supply)
Power supply
Signaling contact
12 VDC
1 x 4-pin
1 x 2-pin
24 VDC
1 x 4-pin
1 x 2-pin
8.3.3
Cable lengths
Table 8- 28 Permitted cable lengths (copper cable - Fast Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE TP torsion cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 45 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 55 m
