Siemens SCALANCE X308-2 User Manual

Technical specifications
8.4 XR-300M technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
173
Table 8- 39 Electrical data: Current consumption and power loss
Device version
(power supply)
Current consumption
Effective power loss
2 x 24 VDC
1.8 A
44 W
1 x 100 to 240 VAC 0.8 to 0.45 A 50 W
Table 8- 40 Electrical data: Overcurrent protection
Device version
(power supply)
Overcurrent protection of the power supply
Non-replaceable fuse
2 x 24 VDC
5 A / 125 V
1 x 100 to 240 VAC 3.15 A / 250 V
Table 8- 41 Electrical data: Signaling contact
Voltage via signaling contact
24 VDC
Switching capacity (resistive load)
max. 100 mA
Table 8- 42 Plug-in terminal block for connectors of the power supply and signaling contact
Device version
(power supply)
Power supply
Signaling contact
2 x 24 VDC
2 x 4-pin
2 x 2-pin
1 x 100 to 240 VAC
1 x 2-pin
1 x 2-pin
8.4.3
Cable lengths
Table 8- 43 Permitted cable lengths (copper cable - Fast Ethernet)
Cable type
Accessory (plug, outlet,
TP cord)
Permitted cable length
IE TP torsion cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 45 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 55 m
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 75 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 85 m
IE FC TP standard cable with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
with IE FC RJ-45 Plug 180
0 to 100 m
