SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
283
Graphics
11
11.1
Dimension drawing
Note
The IE Switches X
-300 are available in small, medium and large variants.
The dimension drawings are shown below.
Small design
Image 11-1 Small design dimension drawing (example used here SCALANCE X306-1LD FE)
