Description of the device
4.2 Product groups
SCALANCE X-300
74 Operating Instructions, 05/2016, A5E01113043-20
P1 P2 P3 P4 P5 P6 P7 P8 P1 P2 P1 P2
Electrical: Gigabit Ethernet Connection type depend-
MM900 media modules
4.2.8.1
MM992-2CUC product characteristics
Possible attachments
The MM992-2CUC media module has the following:
● 2 x 10/100/1000 Mbps, RJ-45 ports electrical with securing collar
Image 4-25 MM992-2CUC [9922GA]
[Device labeling in square brackets]
Note
For connection to electrical networks note
the information in Appendix A.1 and A.2.
