Siemens SCALANCE X308-2 User Manual

Connecting
6.5 Power supply
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
135
Table 6- 6 24 to 48 VDC safety extra-low voltage overview
Device
Device version
(power supply)
24 V safety extra-low voltage
(SELV)
can be connected redundantly
XR324-4M EEC
1 x 24 to 48 VDC
●
2 x 24 to 48 VDC
●
6.5.1.6
24 VDC - product group X-300M PoE
Table 6- 7 24 VDC safety extra-low voltage overview
Device
Device version
(power supply)
24 V safety extra-low voltage
(SELV)
can be connected redundantly
X308-2M PoE
1 x 24 VDC
●
6.5.1.7
24 VDC - XR-300M PoE product group
Table 6- 8 24 VDC safety extra-low voltage overview
Device
Device version (power supply)
24 V safety extra-low voltage
(SELV)
can be connected redundantly
XR324-4M PoE
1 x 24 VDC
●
1 x 24 VDC ●
6.5.1.8
Connector for redundant power supply
Device variants with 1 or 2 power supply units
There are devices variants with one power supply unit or with two power supply units. With
device variants with two power supply units, the 2nd power supply unit is also known as the
redundant power supply unit.
The connection is made using a 4-terminal plug-in terminal block to which two power supply
units can be connected (connected redundantly).
If two power supply units are connected, this is known as a redundant power supply.
Connect two power supplies as described below to achieve a correlation between the pin
assignment and LED display.
