Technical specifications
8.8 XR-300M PoE technical specifications
SCALANCE X-300
200 Operating Instructions, 05/2016, A5E01113043-20
8.8.2
Connectors and electrical data
Table 8- 104 Connection for end devices or network components
Max. number
24 ports
Electrical Port 1 to 8
8 x RJ-45 jacks, MDI-X pinning,
10/100/1000 Mbps (half/full duplex)
power supply for connected devices (PDs) using
Power over Ethernet (PoE) according to
IEEE 802.3af / 802.3at (type 1)
Port 9 to 16:
8 x RJ-45 jacks with MDI-X assignment
10/100/1000 Mbps (half / full duplex)
Media module slots 4 x modular
(2 ports per slot)
Transmitter output (optical) and receiver input The values correspond to those of the permitted
MM900 media modules and SFP transceivers.
Diagnostics port
RJ-11 jack
Table 8- 105 Electrical data: Power supply
Device version
(power supply)
Redundant
power supply unit
Redundant power
supply possible
Power supply
24 VDC No Yes
Rated voltage
24 VDC
Voltage range 19.2 VDC - 28.8
VDC
Permitted voltage
range incl. total
ripple
18.5 VDC - 30.2
VDC
100 to 240 VAC No No 100 to 240 VAC
(85 to 264 V)
Table 8- 106 Electrical data: Current consumption and power loss
Device version
(power supply)
Current consumption
Effective power loss
Max. power consumption
1)
24 VDC
4.2 A
46 W
100 W
100 to 240 VAC
1,3 ... 0.7 A
42 W
96 W
1)
incl. PoE power supply of the connected PoE devices (PDs)
