Siemens SIMATIC IPC547J User Manual

Expanding and assigning parameters to the device
6.6 Installing and removing drives
Operating Instructions, 01/2021, A5E43920357-AA
109
6.6.1.3 Installing a 5.25" mounting frame for removable tray
You can install a 5.25" mounting frame for removable trays in the drive cage type A.
You can then use a 2.5 "or a 3.5" drive in the removable tray.
5.25" mounting frame with removable tray
Requirement
• You know the important safety instructions under "Safety instructions on device and
system extensions (Page 48)".
• The device is equipped with the drive cage type A.
• You know the information under: Installation conditions for drives in drive cage type A
(Page 105)
• An original replacement part. For information on replacement parts, refer to "Hardware
accessories (Page 35)".
• T10 screwdriver
Procedure
1. Fully disconnect the device from the line voltage, see "Switching off the device (Page 72)".
2. Open the device. Be sure to follow the important instructions under "Open the device
(Page 93)".
