Siemens SIMATIC IPC547J User Manual

Technical specifications
8.4 Electromagnetic compatibility
Operating Instructions, 01/2021, A5E43920357-AA
149
8.3.3 Technical specifications of redundant power supply (AC)
Output voltage and maximum current
Voltage
Maximum current
Voltage stability
+12 V
16 A
2
± 5%
+12 V
16 A
2
± 5%
–12 V
0.5 A
± 10%
+5 V
20 A
1
± 5%
+3.3 V
20 A
1
± 5%
+5 Vaux
3.0 A
+5%, -3%
1
The total output of the +5 V and +3.3 V voltage must be ≤ 100 W.
2
The total current of the +12 V voltage must be ≤ 25 A.
The total power of all voltages is max. 350 W.
8.4 Electromagnetic compatibility
See the note in "Applicability of technical specifications (Page 145)".
Interference emission
EN 61000-6-3; EN 61000-6-4;
CISPR 32, EN 55032 Class B; FCC Class A
EN 61000-3-2 class D, EN 61000-3-3
Immunity to interference
EN 61000-6-1; EN 61000-6-2; KN 35
Interference immunity on power
lines
± 2 kV; according to IEC 61000-4-4; burst
± 1 kV; according to IEC 61000-4-5; surge symm
± 2 kV; according to IEC 61000-4-5; surge symm
Noise immunity on signal lines
± 2 kV; according to IEC 61000-4-4; burst; length > 30 m
± 1 kV; according to IEC 61000-4-4; burst; length < 30 m
± 2 kV; according to IEC 61000-4-5; burst; length > 30 m
Immunity to discharges of static
electricity
± 4 kV contact discharge (according to IEC 61000-4-2)
± 8 kV air discharge; (according to IEC 61000-4-2)
Immunity to RF interference
• 10 V/m; 80 up to 2700 MHz
80% AM to IEC 61000-4-3
• 3 V/m; 2.7 to 6 GHz
80% AM to IEC 61000-4-3
• 10 V; 10 kHz up to 80 MHz
80% AM to IEC 61000-4-6
Immunity to magnetic fields
30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8)
