Installing and connecting the device
3.3 Connecting the device
68 Operating Instructions, 01/2021, A5E43920357-AA
3.3.5 Connecting the device to networks
The following options are available for integrating the device into existing or planned system
environments and networks.
Ethernet
Wake on LAN and Remote Boot are supported.
You can use the integrated Ethernet interfaces (10/100/1000 Mbps) for communication and
data exchange with automation devices, such as SIMATIC S7.
You need the "SOFTNET S7" software package for this.
PROFINET
PROFINET can be operated via:
• Standard Ethernet interfaces (RT)
SIMATIC NET
Use this software package to create, operate and configure an innovative network for Field &
Control level. Additional information is available under SIMATIC NET
(http://w3.siemens.com/mcms/automation/en/industrial-
communications/Pages/Default.aspx).
The software package and the documentation are not included in the scope of delivery
Additional information
You can find additional information on the Internet at: Technical support
(https://support.industry.siemens.com/cs/ww/en/)
3.3.6 Securing the cables
The strain relief is used to prevent accidental loosening of cables.
You can mount two strain-relief assemblies.
Requirement
• I/O devices are connected to the respective connections.
• TORX T10 screwdriver
