Technical specifications
8.8 Technical specifications of graphic
156 Operating Instructions, 01/2021, A5E43920357-AA
8.8 Technical specifications of graphic
See the note in "Applicability of technical specifications (Page 145)".
Technical specifications of the internal graphics card
Graphic controller
• Intel® UHD-Grafics 630
integrated in processor:
– Intel
®
Core™ i3-10100E
– Intel
®
Core™ i5-10500E
– Intel
®
Core™ i7-10700E
– Intel
®
Core™ i9-10900E
– Intel
®
Xeon® W-1270E
Graphics memory
Dynamic Video Memory Technology,
uses at least 64 MB in main memory
Resolutions/frequencies/colors
• DVI: 1920 × 1200 at 60 Hz; 32-bit color depth
• DisplayPort: 4096 × 2304 at 60 Hz; 32-bit color depth
•
VGA (via DP-VGA adapter): 2560 × 1600 at 60 Hz; 32-bit color depth
Technical specifications of the optional P400 graphics card
PCIe x16; Triple Head
You can find information on connection options for monitors with adapters under "Hardware
accessories (Page 35)
"
.
• Type: NVIDIA Quadro P400, 2 GB graphics memory
• Maximum resolution:
– 3x DisplayPort:
4096 x 2160 at 60 Hz; 32-bit color depth
– 1x DisplayPort:
5120 × 2880 at 60 Hz; 32-bit color depth
– DVI:
1920 × 1200 at 60 Hz; 32-bit color depth
– VGA:
2048 × 1536 at 60 Hz; 32-bit color depth
