Siemens SIMATIC IPC547J User Manual

Operating Instructions, 01/2021, A5E43920357-AA
145
Technical specifications
8
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The fan cover and filter pad are installed.
•
The device is closed.
•
The connected I/O devices meet the requirements for the respective area of application
(interference emission according to EN 61000-6-3 / IEC 61000-6-3, immunity to
interference according to EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note in "Applicability of technical specifications (Page 145)".
Device with standard enclosure
Device with short enclosure
Article number
6AG4104 -5….-…. (for details, refer to the ordering documentation)
Dimensions
481.4 x 176.6 x 446.6 (W× H × D in mm)
481.4 x 176.6 x 356.6 (W × H × D in mm)
Detailed dimensional specifications can be found in "Dimension drawing of the device
(Page 161)".
Weight
15 up to 23 kg; depending on the equipment
Supply voltage (U
N
)
Single power supply: 100 V AC to 240 V AC (-15%; +10%)
Redundant power supply:
2 × 100 V AC to 240 V AC (-15%; +10%)
-
Transient overvoltages
Device is designed for connection to supply with overvoltage category II (transient overvoltages
up to 2500 V)
Input current
Single power supply:
• Continuous current at 100 V: ≤ 6 A
• Continuous current at 230 V: ≤ 3 A
•
At startup ≤ 80 A for 3.6 ms
Redundant power supply:
• Continuous current at 100 V: ≤ 5 A
• Continuous current at 230 V: ≤ 2.5 A
• At startup ≤ 80 A for 3.6 ms for each module
-
Information on the dimensioning of fuses in higher-level system circuits
A fuse that is designed for a typical tripping current of 6.3 A is integrated in the power supply
unit of the IPC. The pulse currents during startup are also taken into account by the "time lag"
type. In the case of a fault, this fuse ensures the correct disconnection of the device from the
power supply system.
It is recommended that a fuse of at least 6.3 A, plus the power demand of the other devices that
are also supplied via this circuit, be used for protection of the higher-level power supply circuit.
The tripping characteristic of the higher-level protection must take into account the starting
currents of both the IPC and the other devices.
