Siemens SIMATIC IPC547J User Manual

Hardware description
A.3 System resources
Operating Instructions, 01/2021, A5E43920357-AA
181
A.3.4 Memory address assignments
The table describes the assignment of the memory addresses in the delivery state of the
device.
Motherboard SMS-H410
Address (hex)
Description of the basic function
Possible alternative
function
from
to
FED1
0000
FED1
7FFF
Motherboard resources
FED1
1800
FED1
18FF
Motherboard resources
FED1
1900
FED1
19FF
Motherboard resources
E000
0000
EFFF
FFFF
Motherboard resources
FED2
0000
FED3
FFFF
Motherboard resources
FED9
0000
FED9
3FFF
Motherboard resources
FED4
5000
FED8
FFFF
Motherboard resources
FEE0
0000
FEEF
FFFF
Motherboard resources
FE03
8000
FE03
8FFF
Motherboard resources
B113
0000
B113
FFFF
Intel® USB3.1 eXtensible Host Controller 1.10
(Microsoft)
B114
A000
B114
A0FF
Intel® Smbus - A3A3
B108
0000
B10F
FFFF
Intel® I210 Gigabit Network Connection
B107
C000
B107
FFFF
Intel® I210 Gigabit Network Connection
FED0
0000
FED0
03FF
High Precision Event Timer
B110
0000
B111
FFFF
Intel® Ethernet Connection (12) I219-V
FDAF
0000
FDAF
FFFF
Intel® Serial IO GPIO Host Controller - INT3450
FDAE
0000
FDAE
FFFF
Intel® Serial IO GPIO Host Controller - INT3450
FDAC
0000
FDAC
FFFF
Intel® Serial IO GPIO Host Controller - INT3450
FE03
0000
FE03
3FFF
High Definition Audio Controller
FE40
0000
FE40
FFFF
High Definition Audio Controller
FE03
C000
FE03
CFFF
Intel® Management Engine Interface
FD00
0000
FDAB
FFFF
Motherboard resources
