Operating the device
5.4 Onboard RAID system
78 Operating Instructions, 01/2021, A5E43920357-AA
5.4.2 Onboard RAID1 system: Installation options for drives
The 2 hard disks required for an onboard RAID1 system may be installed at the following
locations:
• Drive cage type A (Page 105)
• Drive cage type B (Page 115)
5.4.3 Onboard RAID5 system: Installation options for drives
The hard disks required for an onboard RAID5 system may be installed at the following
locations:
• Drive cage type A (Page 105)
• Drive cage type B (Page 115)
5.4.4 Operating onboard RAID system
5.4.4.1 Configuring the onboard RAID system
If you ordered a device with an onboard RAID system, the onboard RAID system is pre-
configured by default.
If you subsequently set up an onboard RAID system, you still have to configure it.
Requirement
• The drives required for the onboard RAID system are installed in the device, see:
– Onboard RAID1 system: Installation options for drives (Page 78)
– Onboard RAID5 system: Installation options for drives (Page 78)
Setting up the onboard RAID system in the firmware (Create Volume)
1. Switch on the device or restart it.
2. Immediately after turning on the device, as soon as the message "Press <DEL> or
<ESC> to enter setup" appears, press and hold the <Del> or <Esc> button.
The firmware user interface opens. Here you have the following keys available for
navigation:
Action
Key
•
Select entry (then confirm selection)
•
Arrow keys on the keyboard
• Confirm selection • <Enter> key
•
Back to previous window
•
<Esc> key
