SINUMERIK 802D sl Operating and Service Training Manual Page 4
C72
C72
Section 3
New milling tool
The geometry of the tool has to be entered into the tool offset screen befo-
re it can be
used on the machine in a part program.
The followin
g example shows how to perform this task.
After this procedure the tool appears in the tool list.
The length a
nd radius of the tool can now be entered in the left geometry
fields.
Exa
mple:
Important:
After each
value is input the input key must be pressed!
3.1 New milling tool
