SINUMERIK 802D sl Operating and Service Training Manual Page 2
C82
C82
Section 2
Jog
2.1 Jog
First put the control into JO
G mode.
PRESS
The following screen can be seen:
To Jog the axis use the push button for the required axis and the direction to be
moved:
JOG mode is
s
hown here
The use of the feed override switch allows you to regulate
the feed of the cho
sen axis.
If you press the rapid override button at the same time as the selected axis, the
axis will mov
e at rapid speed
until the buttons are rel
eased.
To Next Page
