Section 2
Graphical cycles support
2.1 Graphical cycles support
Graphical c
ycle support in the program editor
The program editor in the control system provi
des you with programming
support to a
dd cycle calls to the program and to enter parameters.
Function
The cycle support consists of three
components:
• Cycle selection
• Input screenforms for parameter assignment
• Help screen for each cycle (is to be found in the interactive screen-
form).
Once you have created an NC program, you can select a “graphical cycle
support eith
er for “drilling” or “milling”.
Here you can choose from
milling or dri
lling cycles.
Once you have chosen a cycle
here you can choose fro
m the
different types of cycles.
