SINUMERIK 802D sl Operating and Service Training Manual Page 2
C31
C31
Section 2
Structure of an alarm
To identify external faults from the generated PLC fault, it is necessary to
understand t
he structure of the alarm.
Structure:
700000
Hydraulic pressure low
700001
Tailstock not in position
700002
Axis %d in parked position
To identify external faults from the generated PLC fault, it is
necessary to
understand t
he structure of the alarm.
Structure:
700000
Hydraulic pressure low
700001
Tailstock not in position
700002
Axis %d in parked position ——-
Axis 1 in parked posit
ion
Alarm Num- Variable = 1 Alarm Text
Axis 2 in parked position
Alarm Number PLC Signal PLC variable NC MD alarm
config
uration
Text File
700000 16000000.0 16001000 14516[0] Alarm 1
700001 16000000.1 16001004 14516[1] Alarm 2
700002 16000000.2 16001008 14516[2] Alarm 3
700003 16000000.3 16001012 14516[3] Alarm 4
700004 16000000.4 16001016 14516[4] Alarm 5
700005 16000000.5 16001020 14516[5] Alarm 6
700006 16000000.6 16001024 14516[6] Alarm 7
700007 16000000.7 16001028 14516[7] Alarm 8
700008 16000001.0 16001032 14516[8] Alarm 9
700009 16000001.1 16001036 14516[9] Alarm 10
700010 16000001.1 16001040 14516[10] Alarm 11
700011 16000001.1 16001044 14516[11] Alarm 12
700012 16000001.1 16001048 14516[12] Alarm 13
.. .. .. .. ..
.. .. .. .. ..
.. .. .. .. ..
.. .. .. .. ..
700063 16000007.7 16001252 14516[63] Alarm 63
Variable definition
%d
Decimal value displayed
%x
Hexadecimal value displayed
%b
Binary value displayed
%o
Octal value is displayed
%u
Unsigned integer is displayed
%f
Floating point number is displayed
PLC Signal
The alarm 700000 is ge
nerated with the corresponding PLC signal, the
reaction fro
m the NC is defined in the NC machine data 14516[index].
2.1 Structure of an alar
m
