SINUMERIK 802D sl Operating and Service Training Manual Page 4
C89
C89
Section 2
G function overview
Group 11: Exact stop, non-modal
Name Meaning
Machine
G09
Velocity reduction, exact positioning
M/T
Group 10: Exact stop - continuous-path mode
Name Meaning
Machine
G60*#
Velocity reduction, exact positioning
M/T
G64 Continuous – path mode
M/T
Group 9: Frame suppression
Name Meaning
Machine
G53
Suppression of current zero offset: including active
settable fra
me G54 - G59
M/T
Group 8: Settable zero offset
Name Meaning
Machine
G500*#
Deactivate all settable G54—G59 if G500 not contain
a value
M/T
G54 Settable zero offset
M/T
G55 Settable zero offset
M/T
G56 Settable zero offset
M/T
G57 Settable zero offset
M/T
G58 Settable zero offset
M/T
G59 Settable zero offset
M/T
Group 7: Tool radius compensation
Name Meaning
machine
G40*#
No tool radius compensation
M/T
G41 Tool radius compensation left of contour
M/T
G42 Tool radius compensation right of contour
M/T
Default for turning * / default for milling #
M = milling / T = turnin
g
