SINUMERIK 802D sl Operating and Service Training Manual Page 2
C10
C10
Locating the Status LED's
Section 2
As can bee seen from the picture below, the status LED´s are located
above the LCD display on the right
hand side, behind the plastic cover.
Section 3
Status of CNC Controller LED's
In the case of ERR (red) a further investigation is required, using internal
and external diagnostic t
ools in general.
In the case
where a fault diagnosis is not possible a status of the LED´s
should be given to the OEM or to Sie
mens service personnel.
2.1 Locating
the Status LED's
3.1 Status of CNC Contr
oller LED's
