Siemens SINUMERIK 802D Training Manual

SINUMERIK 802D sl Operating and Service Training Manual Page 1
C11
C11
MCPA Signal tests
C11
1 Brief description
Module objective:
Upon completion of this
module you can locate the MCPA board in the system and perform a hard-
ware diagnosis of the an
alogue spindle speed setpoint. For a diagnostic of the connected MCP. see
hand book
module C8(Pushbutton test)
Module description:
The MCPA
board (below) can be used to drive an analogue spindle and also to connect an MCP.
Diagnosing
MCP signals can be carried out with the help of module C8 (pushbutton te
st).
When hardware is not
correctly commissioned it can result in damage to hardware, in this case the
MCPA board itself.
Module content:
• Identification of MCPA in the system
• Analogue spindle interface test
Analogue spindle inter-
face test
Section 3
Identification of MCPA
in the sy
stem
Section 2
