5-11. NFC Interface Block
5-11-1. GR-1003 Board
Signals received from the NFC antenna flexible board are input through the 2-pin connector (CN4651) on the GR-1003
board to the NFC system LSI (IC7401), and are then converted to SPI signals in the NFC system LSI (IC7401). The
SPI signals are sent to and received from the system processor (IC6000) on the VC-1045 board through the ZM-1005
board.
Tip
The HXR-MC88 does not support NFC.
