Procedure of the MAC address update:
Note
Perform the below operations after all work has been done.
1. Start the Adjust Manual in the Adjust Station and execute the “Wireless LAN Setting (MAC Address)” on
the ADJUST tab.
2. Operate the unit to initialize of SSID/PW.
Applicable parts:
• VC-1045 BOARD, COMPLETE (SERVICE)
• WF-1008 BOARD, COMPLETE
Note
After the replacement and repair, the MAC address is changed, and thus the re-setting for connection devices is required.
Accordingly, download the Flyer of WLAN Reset (Flyer of WLAN Reset_9834752[][].pdf) and print out it, and attach
it to the set when returning the set to customer.
1-3-3. Notes for Replacing the EVF Display Device (LCD902)
WB adjustment values of each EVF display device (LCD902) are stored on the VC-1045 board.
Therefore, when the EVF display device (LCD902) or the VC-1045 board has been replaced, write WB adjustment
values.
The label which is put on repairing EVF display device:
White balance value
Brightness value
223 460
Procedure of the WB adjustment values writing when the EVF display device (LCD902) is
replaced:
1. Check and write down the adjustment values printed on the repairing EVF display device (LCD902) label.
2. After the EVF display device (LCD902) has been replaced, execute “EVF Data Input” on the ADJUST tab
by using the Adjust Manual in the Adjust Station to write the adjustment values.
Procedure of the WB adjustment values writing when replacing VC-1045 board (in case
adjustment values can be read):
1. Start the Adjust Manual in the Adjust Station before replacing the VC-1045 board, and execute [DATA READ
AND SAVE] in the "ADJUSTMENT DATA BACKUP" on the DATA tab to extract WB adjustment values.
2. Start the Adjust Manual in the Adjust Station after the VC-1045 board has been replaced, and execute [DATA
LOAD AND WRITE] in the "ADJUSTMENT DATA BACKUP" on the DATA tab to write the extracted WB
adjustment values.
When replacing VC-1045 board (in case adjustment values cannot be read):
1. Read the QR code printed in EVF display device (LCD902) using with “QR_Code_Reader_Ver1.0_x64”.
HXR-NX80/HXR-MC88
1-4

Sony HXR-NX80 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	3840 x 2160 pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Built-in microphone	Yes
Audio formats supported	LPCM
Digital zoom	- x
Optical zoom	12 x
Focal length range	9.3 - 111.6 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	32.8 - 393.6 mm
Camera shutter speed	1/10000 s
Display diagonal	3.46 \
Display resolution (numeric)	1560000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Sensor type	CMOS
Total megapixels	14.2 MP
Optical sensor size	1 \
PictBridge	No
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Battery type	NP-FV70A
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	4.4 h
Battery technology	Lithium
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
Viewfinder screen size	0.39 \
Camcorder type	Handheld camcorder
Minimum illumination	1.7 lx
Product color	Black
Cables included	USB
Number of batteries included	1 pc(s)
Maximum image resolution	- pixels

Weight and Dimensions

Depth	287 mm
Width	130 mm
Height	181.5 mm
Weight	1320 g
