Sony HXR-NX80 User Manual

Frame Wiring (2/3)
ZM-1005 BOARD
(Page 7-11)
B
FP-2397
FLEXIBLE
BOARD
1
51
51
1
FP-2202 FLEXIBLE BOARD
LCD902
FP-2400 FLEXIBLE
BOARD
COLOR
EVF UNIT
1
8
1
39
1
39
A
FP-2209 FLEXIBLE
BOARD
(Page 7-11)
BT4301
(LITHIUM BATTERY)
SE7701
PITCH/YAW
SENSOR
C
FP-2263
FLEXIBLE BOARD
(Page 7-11)
FP-2264 FLEXIBLE BOARD
1
33
33 1
TOUCH
PANEL
LCD901
(LCD MODULE)
3.5 INCH
WIDE COLOR
LCD
AUTO/MANUAL
ND FILTER
3 - 2 - 1 - CLEAR
S0408
S0414
S0411
S0411 (For NXR-NX80)
ASSIGN2/
STATUS CHECK
S0403
S0405 S0407
ASSIGN3/
PICTURE PROFILE
WHITE
BALANCE
ASSIGN1/
S＆Q
S0411 (For NXR-MC88)
ASSIGN1
S0401
DISPLAY
S0410
S0412
S0413
SLOT SELECT
THUMBNAIL
SP901
(SPEAKER)
S0406
ISO/GAIN
S0409
SHUTTER SPEED
S0404
IRIS
S0402
MENU
1
250
51
CN4303
129 26 30
2728
CN7100
1
238
39
CN4302
198
15
10
11
12
13
14
16
CN2201
1
250
51
CN4304
1
2
62
60
61
63
CN8060
2
139
38
CN3101
18
CN3102
CN4702
21
CN4703
1
151
250
2
33
32
CN4701
CN3201
1
2
33
32
16
CN3202
1
260
61
CN8040
MS-1037 BOARD
(SIDE A)
MS-1037 BOARD
(SIDE B)
VF-1021 BOARD
(SIDE A)
VF-1021 BOARD
(SIDE B)
CK-1019 BOARD (SIDE A) CK-1019 BOARD (SIDE B)
PD-1054 BOARD
HXR-NX80/HXR-MC88
7-12

Sony HXR-NX80 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	3840 x 2160 pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Built-in microphone	Yes
Audio formats supported	LPCM
Digital zoom	- x
Optical zoom	12 x
Focal length range	9.3 - 111.6 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	32.8 - 393.6 mm
Camera shutter speed	1/10000 s
Display diagonal	3.46 \
Display resolution (numeric)	1560000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Sensor type	CMOS
Total megapixels	14.2 MP
Optical sensor size	1 \
PictBridge	No
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Battery type	NP-FV70A
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	4.4 h
Battery technology	Lithium
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
Viewfinder screen size	0.39 \
Camcorder type	Handheld camcorder
Minimum illumination	1.7 lx
Product color	Black
Cables included	USB
Number of batteries included	1 pc(s)
Maximum image resolution	- pixels

Weight and Dimensions

Depth	287 mm
Width	130 mm
Height	181.5 mm
Weight	1320 g
