Sony HXR-NX80 User Manual

Section 2
Troubleshooting
2-1. Self-diagnosis Function
2-1-1. Self-diagnosis Function
If an error occurs in this unit, the self-diagnosis function starts working and a code consisting of one alphabet and a four-
digit number appears on the LCD. Classification of persons in charge, classification of faulty blocks, and details of errors
can be checked by referring to this indication of five alphanumeric characters in the self-diagnosis code table.
The history of past errors can be checked in “Usage and Diag record” on the DATA tab of the Adjust Manual.
The self-diagnosis function is also described in the operation manual.
2-1-2. Note on the Function of Boards
The boards and functions used in this model are mentioned in the following table.
Board Function
CK board Control switch
CM board Imager
EF board Control switch
FP-2202 board Eyepiece sensor
FP-2269 board Multi interface shoe
FP-2401 board HDMI terminal
GR board NFC module, Control switch
HN board Audio control
HS board Control switch
IP board Control switch
IR board External microphone input, USB terminal, Remote sensor
LA board Remote jack
MS board Memory card connector, Lithium battery, PITCH/YAW angular velocity sensor
PD board LCD control
PH board Control switch
SS board POWER/CHG lamp, Control switch
SW board Control switch
VC board CPU, Lens control, Wireless LAN module, Power control, Other function
VF board EVF control
WF board Wireless LAN antenna
XL board Analog audio input
ZM board Manual Ring control
HXR-NX80/HXR-MC88
2-1

Sony HXR-NX80 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	3840 x 2160 pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Built-in microphone	Yes
Audio formats supported	LPCM
Digital zoom	- x
Optical zoom	12 x
Focal length range	9.3 - 111.6 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	32.8 - 393.6 mm
Camera shutter speed	1/10000 s
Display diagonal	3.46 \
Display resolution (numeric)	1560000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Sensor type	CMOS
Total megapixels	14.2 MP
Optical sensor size	1 \
PictBridge	No
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Battery type	NP-FV70A
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	4.4 h
Battery technology	Lithium
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
Viewfinder screen size	0.39 \
Camcorder type	Handheld camcorder
Minimum illumination	1.7 lx
Product color	Black
Cables included	USB
Number of batteries included	1 pc(s)
Maximum image resolution	- pixels

Weight and Dimensions

Depth	287 mm
Width	130 mm
Height	181.5 mm
Weight	1320 g
