1-3. Notes on Replacing the Part and Printed Wiring Board
1-3-1. Power Supply during Repairs
AC power adaptor
Use the AC power adaptor.
1-3-2. Precaution on Replacing the VC-1045 Board
The board for repair is not recorded the information unique to a model. Therefore the following data are needed to write.
Note
The [LOAD AND WRITE] function in “ADJUSTMENT DATA BACKUP” on the DATA tab in the Adjust Manual
overwrites all data of the unit. Therefore execute the [LOAD AND WRITE] before performing the following operation.
Destination Data
The destination data stored in the repairing board is different from the destination setting stored in the board before
replacement in some cases.
When the board has been replaced with a repairing board, be sure to set the destination.
Method of the destination data write:
Start the Adjust Manual in the Adjust Station and execute the “Destination data write” on the ADJUST tab.
Restore Data
Before replacing the board with a repairing board, be sure to extract the data from the former one.
Method of the data extracting:
Start the Adjust Manual in the Adjust Station and execute the “RESTORE DATA” on the DATA tab.
USB Serial No. and Product ID
The unit is shipped after an ID (USB Serial No.) unique to each unit and an ID (Product ID) unique to each model have
been written.
These IDs have not been written in a new repairing board. Therefore, after the board has been replaced, be sure to write
these IDs to a new repairing board.
Method of the ID writing:
Start the Adjust Manual in the Adjust Station and execute the “PRODUCT ID & USB SERIAL No. INPUT” on
the ADJUST tab.
Update of MAC Address
When a board that contains Wi-Fi has been replaced or when replacing a board that contains the main IC (CPU), the
IC’s unique number (MAC address) must be reloaded.
HXR-NX80/HXR-MC88
1-3

Sony HXR-NX80 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	3840 x 2160 pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Built-in microphone	Yes
Audio formats supported	LPCM
Digital zoom	- x
Optical zoom	12 x
Focal length range	9.3 - 111.6 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	32.8 - 393.6 mm
Camera shutter speed	1/10000 s
Display diagonal	3.46 \
Display resolution (numeric)	1560000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Sensor type	CMOS
Total megapixels	14.2 MP
Optical sensor size	1 \
PictBridge	No
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Battery type	NP-FV70A
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	4.4 h
Battery technology	Lithium
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
Viewfinder screen size	0.39 \
Camcorder type	Handheld camcorder
Minimum illumination	1.7 lx
Product color	Black
Cables included	USB
Number of batteries included	1 pc(s)
Maximum image resolution	- pixels

Weight and Dimensions

Depth	287 mm
Width	130 mm
Height	181.5 mm
Weight	1320 g
