Sony HXR-NX80 User Manual

1-4. Circuit Protection Parts
1-4-1. Replacing Fuses
WARNING
Fuses are essential parts for safe operation. Be sure to use the parts specified in this manual. Replacing a
fuse with an unspecified one may cause fire or electric shock.
CAUTION
If the fuse is replaced while the main power is kept on, this may cause electric shock.
Before replacing any fuse, not only turn off the unit but also remove the battery pack and disconnect the
cable that is connected to the DC IN connector.
The unit is equipped with fuses. The fuses blow if overcurrent flows in the unit due to an abnormality, In that case, turn
off the main power of the unit once, inspect inside of the unit, and then remove the cause of the overcurrent. After that,
replace the defective parts.
Board Name Ref. No. Part Name and Rating Part No.
VC-1045 F0301 FUSE (1608/3.15 A)
!
1-523-393-11
F0302 FUSE (1608/2.0 A)
!
1-523-390-11
F0303 FUSE (1608/1.4 A)
!
1-523-389-11
F0304 FUSE (1608/1.4 A)
!
1-523-389-11
F0305 FUSE (1608/0.5 A)
!
1-523-385-11
F4001 FUSE, MICRO
!
1-523-038-31
F4101 FUSE, MICRO
!
1-523-038-31
F4102 FUSE, MICRO
!
1-523-038-31
HXR-NX80/HXR-MC88
1-8

Sony HXR-NX80 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	3840 x 2160 pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Built-in microphone	Yes
Audio formats supported	LPCM
Digital zoom	- x
Optical zoom	12 x
Focal length range	9.3 - 111.6 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	32.8 - 393.6 mm
Camera shutter speed	1/10000 s
Display diagonal	3.46 \
Display resolution (numeric)	1560000 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Sensor type	CMOS
Total megapixels	14.2 MP
Optical sensor size	1 \
PictBridge	No
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
Battery type	NP-FV70A
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	4.4 h
Battery technology	Lithium
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Viewfinder type	Electronic
Viewfinder resolution	2360000 pixels
Viewfinder screen size	0.39 \
Camcorder type	Handheld camcorder
Minimum illumination	1.7 lx
Product color	Black
Cables included	USB
Number of batteries included	1 pc(s)
Maximum image resolution	- pixels

Weight and Dimensions

Depth	287 mm
Width	130 mm
Height	181.5 mm
Weight	1320 g
