VL1500K5 (’05-MODEL) 121
EXTERIOR PARTS
SEAT REMOVAL
This section gives only exterior parts removal procedure which
differ from that of the VL1500K4 (’04-MODEL). For details refer
to the chapter 6 of Service Manual.
• Remove the rear seat
1.
'
• Remove the seat bracket
2 and front seat
3.
SEAT INSTALLATION
Installation is in the reverse order of removal.
Pay attention the following points:
• With the recessed part
1 of the rear seat engaged with the
tongue
2 of the front seat bracket, install the rear seat.
Be careful not to scratch the rear fender.
