VL1500K5 (’05-MODEL) 39
NOTE:
The above form is a standard sample. The form should be modified according to conditions and characteris-
tics of each market.
VISUAL INSPECTION
• Prior to diagnosis using the mode select switch or SDS, perform the following visual inspections. The rea-
son for visual inspection is that mechanical failures (such as oil leakage) cannot be displayed on the
screen with the use of mode select switch or SDS.
* Engine oil level and leakage (!VL1500 Service Manual 2-6)
* Fuel level and leakage (!Page
8)
* Clogged air cleaner element (!VL1500 Service Manual 2-4)
* Battery condition (!VL1500 Service Manual 7-36)
* Throttle cable play (!Page 9)
* Vacuum hoses looseness, bend and disconnection
*Broken fuse
* FI light operation (!Page 33 and 140)
* Each warning light operation (!Page 140)
* Speedometer operation (!Page 141)
* Exhaust gas leakage and noise (!Page 11)
* Each coupler disconnection
* Clogged oil cooler fins (!VL1500 Service Manual 3G-6)
MOTORCYCLE/ENVIRONMENTAL CONDITION WHEN PROBLEM OCCURS
Environmental condition
Weather
Fair Cloudy Rain Snow Always Other
Temperature Hot Warm Cool Cold ( °C/ °F) Always
Frequency Always Sometimes ( times/ day, month) Only once
Under certain condition
Road Urban Suburb Highway Mountainous ( Uphill Downhill)
Tarmacadam Gravel Other
Motorcycle condition
Engine condition
Cold Warming up phase Warmed up Always Other at starting
Immediately after start Racing without load Engine speed ( r/min)
Motorcycle con-
dition
During driving: Constant speed Accelerating Decelerating
Right hand corner Left hand corner
At stop Motorcycle speed when problem occurs ( km/h, mile/h)
Other
