14 VL1500K5 (’05-MODEL)
ENGINE REMOVAL AND INSTALLATION
ENGINE REMOVAL
The engine removal procedure is different from that of the
VL1500K4 (’04-MODEL). For details other than the removal pro-
cedure, refer to the VL1500 Service Manual.
• Remove the seats. (!Page 121)
• Remove the PAIR cover
1.
• Disconnect the PAIR hoses
2 from the pipes.
• Remove the PAIR control solenoid valve nuts
3.
• Disconnect the PAIR control solenoid valve coupler
4 and
PAIR hose
5.
• Remove the PAIR control solenoid valve
6.
SAMPLE
To Next Page
