VL1500K5 (’05-MODEL) 165
WATTAGE
Unit: W
BRAKE + WHEEL
Unit: mm (in)
ITEM
SPECIFICATION
E-03, 28, 33 E-24 Others
Headlight HI 60 ←←
LO 55 ←←
Position/Parking light
* 12/5
Brake light/Taillight 21/5 ←←
Turn signal light Front 21/5 21 ←
Rear 21 ←←
Speedometer light
* LED
← ←
Turn signal indicator light
* LED
← ←
High beam indicator light
* LED
← ←
Neutral indicator light
* LED
← ←
Oil pressure indicator light LED ←←
* FI indicator light LED
← ←
ITEM STANDARD LIMIT
Rear brake pedal height 98
(3.86)
—
Brake disc thickness
Front
4.8 – 5.2
(0.189 – 0.205)
4.5
(0.18)
Rear
6.6 – 7.0
(0.260 – 0.276)
6.3
(0.25)
Brake disc runout
—
0.30
(0.012)
Master cylinder bore
Front
15.870 – 15.913
(0.6248 – 0.6265)
—
Rear
12.700 – 12.743
(0.5000 – 0.5017)
—
Master cylinder piston diam.
Front
15.827 – 15.854
(0.6231 – 0.6242)
—
Rear
12.657 – 12.684
(0.4983 – 0.4994)
—
Brake caliper cylinder bore
Front
30.230 – 30.306
(1.1902 – 1.1931)
—
Rear
30.230 – 30.306
(1.1902 – 1.1931)
—
Brake caliper piston diam.
Front
30.150 – 30.200
(1.1870 – 1.1890)
—
Rear
30.150 – 30.200
(1.1870 – 1.1890)
—
Wheel rim runout
Axial —
2.0
(0.08)
Radial —
2.0
(0.08)
Wheel axle runout
Front —
0.25
(0.010)
Rear —
0.25
(0.010)
