VL1500K5 (’05-MODEL) 175
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING
*1
*2
*3
20 – 40 mm
(0.79 – 1.57 in)
20 – 40 mm
(0.79 – 1.57 in)
15 – 20 mm
(0.59 – 0.79 in)
15 – 20 mm
(0.59 – 0.79 in)

1
PAIR control solenoid valve with PAIR reed valve
*1
Connect the air hose to the air cleaner
box.

2 Cushion seat (Apply adhesive agent to the cushion seat) *2 Matching mark (yellow).

3 Wiring harness *3 Matching mark (white).
