158 VL1500K5 (’05-MODEL)
TIGHTENING TORQUE
* FI SYSTEM AND INTAKE AIR SYSTEM
* CHASSIS
ITEM
N·m kgf-m lb-ft
IAT sensor 20 2.0 14.4
HO2 sensor (For E-02, 19, 24) 25 2.5 18.0
EOT sensor 22 2.2 16.0
Fuel pump mounting bolt 10 1.0 7.0
STPS mounting screw 3.5 0.35 2.5
TPS mounting screw 3.5 0.35 2.5
Fuel delivery pipe mounting screw 5 0.5 3.5
Fuel delivery pipe hose mounting screw 5 0.5 3.5
ITEM
N·m kgf-m lb-ft
Front fork cap bolt 23 2.3 16.5
Front fork upper clamp bolt 23 2.3 16.5
Handlebar set bolt 23 2.3 16.5
Handlebar holder nut 70 7.0 50.5
