168 VL1500K5 (’05-MODEL)
EMISSION CONTROL SYSTEMS
FUEL INJECTION SYSTEM
VL1500K5 motorcycles are equipped with a fuel injection system for emission level control.
This fuel injection system is precision designed, manufactured and adjusted to comply with the applicable
emission limits.
1 Fuel tank
7 Fuel mesh filter (For low pressure)
2 Fuel filter (For high pressure)
8 Fuel pump
3 Fuel pressure regulator
A Before-pressurized fuel
4 Fuel delivery pipe
B Pressurized fuel
5 Fuel injector
C Relieved fuel
6 Fuel feed hose
