164 VL1500K5 (’05-MODEL)
* THROTTLE BODY
ELECTRICAL
Unit: mm (in)
ITEM SPECIFICATION
ID No.
10F0 (For E-02, 19, 03, 24, 28), 10F1 (For E-33)
Bore size
36 mm
Fast idle r/min 1 400 – 2 000 r/min When cold engine
Idle r/min 1 000 ± 100 r/min
Throttle cable play 2.0 – 4.0 mm
(0.08 – 0.16 in)
ITEM SPECIFICATION NOTE
Firing order R · F
Spark plug
Type
NGK:
DPR7EA-9
DENSO:
X22EPR-U9
Gap
0.8 – 0.9
(0.031 – 0.035)
Spark performance Over 8 (0.3) at 1 atm.
* CKP sensor resistance 178 – 242 Ω Bl – G
* CKP sensor peak voltage 2.4 V and more
Ignition coil resistance
Primary 1 – 7 Ω
Terminal –
Terminal
Secondary 18 – 28 kΩ
Plug cap –
Terminal
Ignition coil primary peak voltage
Front
* 180 V and more
B/Y –
Ground
Rear
* 180 V and more W – Ground
Generator coil resistance 0.1 – 1.0 Ω
* W – W
Generator Max. output
*Approx. 375 W at 5000 r/min
Generator no-load voltage
(when engine is cold)
80 V (AC) and more at 5 000 r/min
Regulated voltage 13.5 – 15.0 V at 5 000 r/min
Decomp. solenoid resistance 0.1 – 1.5 Ω
Fuel pump resistance 70 – 110 Ω
Starter relay resistance 3 – 6 Ω
* GP switch voltage 0.6 V and more (From 1st to top)
Battery Type designation
* FTZ16-BS-1
Capacity
* 12 V 64.8 kC (18 Ah)/10 HR
Fuse size
Headlight
HI 10 A
LO 10 A
Signal 15 A
Ignition 15 A
Fuel 10 A
Power source 10 A
Main 30 A
