2 VL1500K5 (’05-MODEL)
SWITCHES........................................................................................................ 142
BATTERY.......................................................................................................... 143
WIRING HARNESS, CABLE AND HOSE ROUTING....................................... 144
EXTERIOR PARTS INSTALLATION................................................................ 153
SPECIAL TOOLS.............................................................................................. 157
TIGHTENING TORQUE .................................................................................... 158
SERVICE DATA................................................................................................ 159
EMISSION CONTROL SYSTEMS .................................................................... 168
PAIR (AIR SUPPLY) SYSTEM INSPECTION .................................................. 172
PAIR (AIR SUPPLY) SYSTEM DIAGRAM ....................................................... 174
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING ............................................ 175
HEATED OXGEN SENSOR (HO2S) INSPECTION (FOR E-02, 19, 24).......... 176
WIRING DIAGRAM ........................................................................................... 177
COUNTRY AND AREA CODES
The following codes stand for the applicable country (-ies) and area (-s).
CODE COUNTRY or AREA EFFECTIVE FRAME NO.
E-03
E-19
E-24
E-28
E-33
U.S.A. (Except for California)
EU
Australia
Canada
California (U.S.A.)
JS1VY52A 52100001 –
JS1AL211100105237 –
JS1AL211300100688 –
JS1VY52A 52100001 –
JS1VY52A 52100001 –
