SYM 8. V-BELT DRIVING SYSTEM/KICK STARTER ARM
8-1
MECHANISM DIAGRAM ................... 8-1
MAINTENANCE DESCRIPTION ....... 8-2
TROUBLE DIAGNOSIS..................... 8-2
LEFT CRANKCASE COVER............. 8-3
KICK STARTER ARM.........................8-3
DRIVING BELT...................................8-4
SLIDING PULLEY...............................8-6
CLUTCH/DRIVEN PULLEY...............8-9
MECHANISM DIAGRAM
5.5~6.0kgf-m
1.0~1.5kgf-m
5.5~6.0kgf-m
5.0~6.0kgf-m
