SYM 13. BRAKE
13-1
MECHANISM DIAGRAM-FRONT
DISC BRAKE SYSTEM......................13-1
MECHANISM DIAGRAM-REAR
DRUM BRAKE SYSTEM....................13-2
MAINTENANCE INFORMATION........13-3
TROUBLE DIAGNOSIS......................13-4
HYDRAULIC BRAKE SYSTEM
INSPECTION......................................13-5
BRAKE FLUID
REPLACEMENT/AIR-BLEED ............ 13-6
BRAKE CALIPER ..............................13-7
BRAKE DISC......................................13-8
BRAKE MASTER CYLINDER............13-8
DRUM BRAKE-DRUM........................13-11
BRAKE LING......................................13-11
BRAKE PANEL.................................. 13-12
MECHANISM DIAGRAM
Front Disc Brake System
5.0~7.0 kgf-m
4.0~4.5 kgf-m
0.8~1.0 kgf-m
3.3~3.7 kgf-m
2.8~3.2 kgf-m
