SYM 12. BODY COVER
12-1
MAINTENANCE INFORMATION....... 12-2
HANDLE COVER............................... 12-3
FRONT COVER................................. 12-4
FRONT INNER BOX.......................... 12-5
BODY COVER/REAR CENTER
COVER/REAR FENDER.....................12-6
FRONT CENTER COVER..................12-8
LUGGAGE BOX .................................12-8
FLOOR PANEL...................................12-8
SIDE COVER......................................12-9
UNDER COVER .................................12-10
Double Seat
F
ront
h
andle
cover
Under cover
Luggage box
Rear carrier
Left side cover
Left body
cover
Rear h
andle
cover
Floor panel
FR.
Inner
box
Right side cover
Right body
cover
RR. mudguard
FR. Inner box lid
Top cover
Handle visor
Under spoiler
F
ront cover
spoile
Center cover
Front fender
RR.
fender
mudguard
Tail light lens
RR. fender
Inner fender
