12. BODY COVER SYM
12-8
FRONT CENTER COVER
Removal
Remove the 4 screws bolt in the battery
cover.
Remove the 1 screw in the front center
cover.
Remove the front center cover.
Installation
Install the front center cover according to the
reverse procedure of removal.
LUGGAGE BOX
Removal
Open the seat.
Remove the 4 bolts in front of the luggage
box.
Remove the 2 bolts in the rear of the
luggage box.
Remove the luggage box and the double
seat.
Installation
Install the luggage box according to the
reverse procedure of removal.
Front center cover
4 bolts
2 bolts
To Next Page
