12. BODY COVER SYM
12-4
FRONT COVER
Removal
Remove the top cover.
Remove the 1 mounting bolt of front cover
from the frame.
Remove the front under cover 4 mounting
screws between the front under cover and
the frame .
Remove the 2 mounting screws between the
front cover and the left/right side cover.
bolt
×
1
Top cover
screws
2
×
2
Screws
1
×
2
