SYM
12. BODY
C
OVER
12
-
9
FLOOR PANEL
Removal
Remove the
4
screws
in the battery cover.
Remove the
1
s
crew
in the front center
cover.
Remove
t
he
front center cover.
Remove the
4
bolt
s
in
the
floor panel
.
Remove
t
he luggage box and the double
seat
.
Remove the
2
bolts
between the
floor panel
and the frame.
B
olts
1
×
2
s
crew
s
×
4
s
crew
×
1
Front center cover
s
crew
s
×
4
40
42
