SYM 10. A.C. GENERATOR/STARTING CLUTCH
10-1
MECHANISM DIAGRAM ................... 10-1
PRECAUTIONS IN OPERATION ...... 10-2
A.C.GENERATOR REMOVAL........... 10-3
RIGHT CRANKCASE COVER
REMOVAL ..........................................10-4
STARTING CLUTCH ..........................10-5
RIGHT CRANKCASE COVER
INSTALLATION ..................................10-8
MOUNTED COIL SET
INSTALLATION ..................................10-8
FLY WHEEL INSTALLATION.............10-8
MECHANISM DIAGRAM
9.0~10.0kgf-m
1.0~1.4kgf-m
1.5~2.0kgf-m
1.3~1.7kgf-m
5.0~6.0kgf-m
