12. BODY COVER SYM
12-2
MAINTENANCE INFORMATION
Body covers disassemble sequence:
Ÿ Be careful not to damage various covers in disassembly or re-assembly operation.
Ÿ Never injure hooks molded on the body covers in disassembly or re-assembly operation.
Ÿ Align the buckles on the guards with slot on the covers.
Ÿ Make sure that each hook is properly installed during the assembly.
Ÿ Never compact forcefully or hammer the guard and the covers during assembly.
Left/right side cover
Top cover
Luggage box & Seat
Rear carrier
Front cover
Front Handle cover
Rear handle cover
Under cover
Rear fender
Tail light
Front fender
Front center cover
Front wheel
Under spoiler
Floor panel
Front inner box
