13. Cooling System
13-2
General Information
Warning:
z Refill the radiator with distilled water or specified additives.
z Add coolant to the reservoir.
z The cooling system can be serviced on the motorcycle.
z Never spill the coolant to the painted surface.
z Test the cooling system for any leakage after the repair.
z Please refer to Section 17 for inspection of the temperature sensor switch for the fan motor and
the water thermometer.
Technical Specification
Item Specification
Pressure to open filler cap 0.75~1.05 kg/cm
2
Capacity of coolant: Engine + radiator
Reservoir upper
780 c.c.
420 c.c.
Thermostat
Begins to activate at 71-80℃
Stroke: 3.5 ~ 4.5 mm/80℃
Boiling point
Not-pressure: 107.7℃
Pressurized: 125.6℃
Torque Value
For water pump rotor 1.0~1.4kgf-m
Tools Requirement
Special tools
Water pump bearing driver (6901)
Water pump oil seal driver (Inner)
Water pump mechanical seal driver
Inner bearing puller
․While the engine is running, never attempt to open the radiator filler cap, the pressurized hot
coolant may shoot out and cause serious scalding injury. No maintenance work is allowed to
perform unless the engine is completely cooled down.
